CONSTRUCTION ELEVATOR SC200-200 FOR SALE
Year:2021

Load Capacity:2x2000kg

Speed:0-40m-min

Usage:Construction Hoist

Size:3.2x1.5x2.5

Maximum working range:500m
产品详情


The Construction Elevator SC200-200EB is a high-performance construction elevator mainly used in construction sites and other situations for vertical transportation of people and materials.
This elevator has the following features:
High load capacity: the maximum load can be up to 2000 kg, which can meet the needs of most construction sites.
Fast lifting speed: the maximum lifting speed can be up to 60 meters per minute, which can greatly improve the construction efficiency.
Safe and reliable: Equipped with various safety protection devices, such as overload protection, a fall arrester, a limit switch, etc., to ensure the safe operation of the lift.
Easy to operate: adopting an advanced control system makes it easy to operate and easy to master.
Strong adaptability: it can be customized according to different construction requirements and is suitable for various construction sites.

model numberSC200/200 EB
   Rated load capacitykg2000/2000
   Rated erection loadkg1000/1000
   Rated load of jibkg200
   Maximum lifting heightm500
  Rated speedm/min0-40
   Fall arrester
SAJ40-1.2A
   Cage internal dimensions (L×W×H)m3.2×1.5×2.5
   Standard section specifications (L×W×H)mm650×650×1508
   Motor power (worm gear)kw2×2×13
